KERN® Analogue Shore hardness tester HBA 100-0, Measuring range Shore [Max] 100 HA Readability Shore [d] 1 HA Tolerance (% of [Max]) 3%
Roll over image to zoom in Click on image to zoom
KERN® Analogue Shore hardness tester HBA 100-0, Measuring range Shore [Max] 100 HA Readability Shore [d] 1 HA Tolerance (% of [Max]) 3%

KERN® Analogue Shore hardness tester HBA 100-0, Measuring range Shore [Max] 100 HA Readability Shore [d] 1 HA Tolerance (% of [Max]) 3%

Kern SKU: HBA 100-0
Price: €118.00 Excluding VAT
Why Choose Inspection Equipment
Fast Dispatch Orders dispatched quickly from our extensive warehouse stock.
46 Years of Experience Established in 1980 with decades of metrology expertise.
Technical Support Experienced specialists available before and after your purchase.
25,000+ Products One of Ireland’s largest ranges of precision measurement equipment.
Expert Advice We will help you select the right instrument for your application.
Need help choosing the right product?

  • Description

    • Typical application: measurement of penetration (Shore)
    • Particularly recommended for internal comparison measurement. Standard calibrations e.g. to DIN 48-4 are not possible because of very narrow standard tolerances
    • Shore A: Rubber, elastomers, neoprene, silicone, vinyl, so plastics, felt, leather and similar material
    • Max mode: Records the peak value indication by drag pointer
    • Can be attached to the test stand SAUTER TI-AC
    • Delivery in a plastic box

  • Technical Data

    Hardness scales Shore A
    Measuring range Shore [Max] 100 HA
    Readability Shore [d] 1 HA
    Tolerance (% of [Max]) 3%
    Scale - Display type Analogue
    Material housing metal
    Measuring probe diameter 18 mm
    Test force Hardness measurement 10 N
    Product family HB
    GTIN/EAN number 4045761140172
