ETALON, 01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCH
ETALON, 01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCH
Roll over image to zoom in Click on image to zoom
ETALON, 01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCHETALON, 01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCH

ETALON, 01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCH

Tesa SKU: 01426028
List price: €185.00 Offer price: €150.00 Excluding VAT

Optional Services

Supplied with a UKAS calibration certificate. Allow 7-10 working days for the calibration
Add your Gauge ID, asset/serial number, company name, logo or QR code.
Tesa design - Swiss made
Factory standard
1.1mm Scale interval
Dial: rotating dial with dial lock
0.210" Range of indication maximum plunger travel
Material hardness full-metal dial casing.
Stainless steel fixing shank and plunger, hardened.
Adjustable tolerance marks.
M2,5 mounting thread for the measuring insert.
Mounted insert with a 3mm diameter steel ball tip
Inspection report with a declaration of conformity
Dial locking knob. 0.01" Revolution
Part Number 01426028
Description MERCER Dial indicator, 2.25 in dial diameter
Range 0 - 0.2"
Resolution 0.0001"
Measurement Accuracy +/-0.0005"
Reading 0-50-0
Dial Colour White
Item Diameter 2.283 inches
Stem Outside Diameter 8MM
Thread Style M2.5
ETALON,01426028 Dial gauge DIAL INDI. 240-1 FACE SIZE 58MM GRADUATION 0.0001'' INCH

No technical information is currently available.

No application information is currently available.

No videos or documents are currently available.
