| Digital/Analog: |
Analog
|
| Delivered: |
In a paper box with spanner 200154
|
| Inch-Metric: |
Metric
|
| Range: |
0 - 2.5 mm
|
| Graduation: |
0,0001 mm
|
| Max. Permissible Error J MPE: |
±5 µm / ±1,5 µm
|
| Maximum Permissible Error J MPE (Narrow): |
±1,5 µm
|
| Spindle end: |
Flat
|
| Stem Ø: |
12 mm
|
| Stem: |
w/ clamp nut
|
| Fixture thickness for clamp nut: |
9.5 mm
|
| Special features: |
Fine Graduation
|
| Measuring face: |
Carbide tipped
|
| Mass: |
150 g
|
Technical information will be added shortly.
Application information will be added shortly.
Product videos and documents will be added shortly.
