Metric Digimatic Micrometer 25-50mm, IP65, Ratchet Thimble, 293-245-30
Roll over image to zoom in Click on image to zoom
Metric Digimatic Micrometer 25-50mm, IP65, Ratchet Thimble, 293-245-30

Mitutoyo Metric Digimatic Micrometer 25-50mm, IP65, Ratchet Thimble 293-245-30

Mitutoyo SKU: 293-245-30
List price: €340.00 Offer price: €264.00 Excluding VAT
Why Choose Inspection Equipment
Fast Dispatch Orders dispatched quickly from our extensive warehouse stock.
46 Years of Experience Established in 1980 with decades of metrology expertise.
Technical Support Experienced specialists available before and after your purchase.
25,000+ Products One of Ireland’s largest ranges of precision measurement equipment.
Expert Advice We will help you select the right instrument for your application.
Need help choosing the right product?

Metric Digimatic Micrometer IP65 25-50mm Ratchet Thimble W/O Output 293-245-30

Series 293
This IP65 micrometer offers outstanding accuracy, without data output, is highly robust, and offers the following benefits:

  • Oil-resistant material used for all plastic parts
  • Extraordinary battery life of 2,4 years
  • Excellent resistance against water and dust enables this micrometer to be used in machining situations that include splashing coolant fluid.

Specifications

  • Digital/Analog: Digital
  • Inch-Metric: Metric
  • Range: 25 - 50 mm
  • Digital step: 0.001 mm
  • Maximum Permissible Error J MPE: ±1 µm
  • Accuracy: ±1 µm
  • Flatness: 0.3 µm
  • Parallelism: 1 µm
  • Display: LCD, character height 7.5 mm
  • Measuring spindle: With spindle lock, ø6.35 mm, spindle pitch 0.5 mm
  • Scale: Thimble and sleeve satin chrome finish, ø18 mm
  • Power supply: 1 battery SR-44
  • Battery life: Approx. 2.4 years
  • Delivered: including the box, key, 1 battery, gauge block (from 25 mm upward), up to 50 mm measuring range with factory certificate
  • ABS / INC (INC ZERO): Yes
  • Auto Power OFF after 20 min. nonuse: Yes
  • Function lock: Yes
  • HOLD: Yes
  • Mass: 270 g
