Mark-10 SKU: ST50E
Price: €995.00 Excluding VAT

Torque tester, 50 x 0.05 lbin, 580 x 0.5 kgFmm, 570 x 0.5 Ncm, 110V

ST Torque Tool Testers present a simple yet accurate solution for testing torque screwdrivers, wrenches, and other tools. Applications exist in manufacturing facilities in virtually every industry. The ST features a solid aluminum housing, making it rugged enough for many years of service in production or laboratory use, while a universal receptacle with square drive and grooves accepts common bits and attachments. The ST captures peak torque in both clockwise and counter clockwise directions.
Note: The ST cannot be used with impact or air tools

Simply place the torque tool into the universal receptacle and twist. The readout will show the torque value in the clockwise or counter clockwise direction.





Torque tester, 50 x 0.05 lbin, 580 x 0.5 kgFmm, 570 x 0.5 Ncm, 110V

  • Torque tester, 50 x 0.05 lbin, 580 x 0.5 kgFmm, 570 x 0.5 Ncm, 110V
  • Outstanding value
  • Accepts many types of torque tools
  • Selectable units of measurement
  • Peak memory for clockwise and counterclockwise readings
  • RS-232 and Mitutoyo (Digimatic) outputs
  • Optional bench mounting bracket
  • Solid aluminum housing
  • 3 capacities available: 12 lbin (135 Ncm), 50 lbin (570 Ncm), 100 lbin (1150 Ncm)
  • Battery or AC operation
  • Mounting holes for bench mounting
  • Battery or AC operation
  • Mounting holes for bench mounting
  • Accuracy: ±0.5% of full scale ±1 digit
  • Sampling rate: 65 readings/sec
