MarCal Digital Caliper 16 EWR Square Depth Rod (4103063) 0-6"/150mm With Thumb Roller
MarCal Digital Caliper 16 EWR Square Depth Rod (4103063) 0-6"/150mm With Thumb Roller
Roll over image to zoom in Click on image to zoom
MarCal Digital Caliper 16 EWR Square Depth Rod (4103063) 0-6"/150mm With Thumb RollerMarCal Digital Caliper 16 EWR Square Depth Rod (4103063) 0-6"/150mm With Thumb Roller

MarCal Digital Caliper 16 EWR Square Depth Rod (4103063) 0-6"/150mm With Thumb Roller

Mahr SKU: 4103063
List price: €175.00 Offer price: €75.00 Excluding VAT

Optional Services

Supplied with a UKAS calibration certificate. Gauge is in stock; calibration adds 7–10 working days.
Add your Gauge ID, asset/serial number, company name, logo or QR code.

Optional Accessories

Select any accessories you require. Click a part number to view the accessory details.

MHC 101-0110 Centreline accessory kit for Calipers
Part number: 101-0110  → View product
MHC 101-0008 Caliper Centreline Gauge Set
Part number: 101-0008  → View product
MHC 101-0020 Caliper Accessory set Caliper Accessory Kit: 8 Pc, Use with Vernier, Dial & Electronic Calipers, Includes (2) Ball Contact Points, (2) Conical Contact Points, (2) Flat Contact Points & (2) Spline Contact Points
Part number: 101-0020  → View product
Mitutoyo CERA Caliper Checker 20-300mm 515-555
Part number: 515-555  → View product
Mitutoyo 516-122-10 Caliper Check Set Consisting 41.3mm, 131.4mm Gauge blocks and 20mm ring Gauge Grade 1
Part number: 516-122-10  → View product
Mitutoyo Depth Base Attachment for Caliper, 100mm
Part number: 050084-10  → View product
Mitutoyo Depth Base Attachment for Caliper, 75mm
Part number: 050083-10  → View product

MarCal Digital Caliper 16 EWR without data output, with Flat Depth Rod and Friction Wheel - 4103063

  • All Mahr digital calipers with "Reference" logo are equipped with the innovative Reference-System.
  • The zero position just has to be set once: after setting the zero position, the zero remains stored for all further measurements. Therefore, once the caliper is switched ON or the slide is moved, the caliper is immediately ready for measurement. The need to reset to zero with a conventional caliper once the caliper is switched on has now become obsolete.
  • Functions:ON/OFF, RESET (Set display to zero), mm/inch, Reference-Lock/Unlock, Auto-ON/OFF
  • Immediate measurement due to the Reference system
  • Excellent resistance against dust, coolants and lubricants, Protection Class IP67
  • Life of the battery up to 3 years
  • High contrast Liquid Crystal Display with 8.5 mm high digits
  • Lapped guideway
  • Dirt wipers are integrated in the slide
  • Max measuring speed 2.5 m/s (100“/s)
  • Slide and beam made of hardened stainless steel
  • Measuring blades for inside measurement
  • Step measuring function
  • Locking screw
  • Supplied with: Case, battery, operating instructions

No technical information is currently available.

No application information is currently available.

No videos or documents are currently available.
