| Magnetic force: |
600 N vertical retractile force
|
| Clamping device: |
magnetic
|
| Clamping force (vertical): |
600 N
|
| Base size (LxWxH): |
59 x 50 x 55 mm
|
| Total height: |
232 mm
|
| Fine adjustment: |
with fine feed wheel +-4°
|
| Stem hole ø: |
3/8" / 9.53 mm, 6 mm, 8 mm (with stem bush)
|
| Working radius: |
170.5 mm
|
| Delivered: |
In a carton box with stem bush 02AZC291
|
Technical information will be added shortly.
Application information will be added shortly.
Product videos and documents will be added shortly.
