KERN® Leeb hardness tester HMO Measuring range Leeb 170 – 960, Units HL, HV, HB, HRB, HRC, MPa
Roll over image to zoom in Click on image to zoom
KERN® Leeb hardness tester HMO Measuring range Leeb 170 – 960, Units HL, HV, HB, HRB, HRC, MPa

KERN® Leeb hardness tester HMO Measuring range Leeb 170 – 960, Units HL, HV, HB, HRB, HRC, MPa

Kern SKU: HMO
Price: €2,219.41 Excluding VAT

  • Description

    • LCD touchscreen with touch pen
    • Automatic recognition of the impact (rebound) sensor connected to the SAUTER HMO
    • Mobility: In comparison with stationary table-top devices and testing devices with an internal sensor, using the SAUTER HMO offers the highest level of mobility and flexibility
    • All measurement directions possible (360°) by defining the direction of impact on the device
    • USB socket for connection to the printer and charging the batteries
    • Hardness test block for calibration included
    • Internal data memory for up to 500 values
    • Mini statistics function: Displays the measure value, the average value, the difference between the maximum and minimum values, date and time
    • Measurement value display: (B and C), Vickers (HV), Brinell (HB), Leeb (HL), tensile strength (MPa)
    • Automatic unit conversion: The measuring result is automatically converted into all specified hardness units
    • Delivered in a robust carrying case

Technical Data

Measuring range Leeb 170 – 960
Readability [d] hardness (Hlx) 1
Tolerance (% of [Max]) 1%
Units HL, HV, HB, HRB, HRC, MPa
Hardness scales HLD
Test object thickness [Min] 3 mm
Test object minimum weight [Min] 3 kg
Memory function
Statistic function
Function for averaging
Material housing plastic
Measuring probe diameter 2 cm
Measuring probe length 14,6 cm
Test block inclusive
Product family HMO
GTIN/EAN number 4045761139664

Technical information will be added shortly.

Application information will be added shortly.

Product videos and documents will be added shortly.
