- 1. Measuring at power-on with ABS mode, no calibration required.
- 2. High-quality material with stainless Steel throughout.
- 3. High-precision machining process ensures product quality.
- 4. Easy to read with the large HD-LCD screen display.
- 5. Numbers invert for Working Overhead.
- 6. Switch to a supplementary angle.
- 7. It features a fine adjustment knob for exact settings.
- 8. Lock measuring data at any angle with a good locking function.
A digital bevel protractor is a versatile measuring tool designed to accurately measure and transfer angles in various applications, including woodworking, metalworking, construction, and engineering. It combines the functionality of a traditional bevel protractor with the precision and convenience of a digital display.
Key features and benefits of a digital bevel protractor:
Digital readout: The protractor features a digital display that provides precise and easy-to-read angle measurements in degrees, eliminating the need for manual calculations or estimations.
Adjustable arms: The protractor typically has two adjustable arms that can be positioned and locked at any angle. This allows for accurate measurement of angles between surfaces, edges, or objects.
Hold function: Many digital bevel protractors have a hold function that allows you to freeze the displayed angle measurement, even when the arms are moved. This is useful for transferring angles from one surface to another.
Backlit display: Some models come with a backlit display, making it easier to read measurements in low-light conditions.
Multiple measurement modes: Some digital bevel protractors offer multiple measurement modes, such as absolute angle measurement (measuring the angle from a fixed reference point) and relative angle measurement (measuring the angle change from a starting position).
Compact and portable: Digital bevel protractors are generally compact and lightweight, making them easy to carry and use in various job site or workshop environments.
Durable construction: These protractors are typically made of durable materials, such as stainless steel or aluminum, to withstand the rigors of everyday use.
Professional Digital Bevel Protractor
High Precision Measurement: Provides highly accurate angle measurements with a typical accuracy range of ±0.1 degrees, ideal for precision work.
Specifications
| Resolution | 0.01° |
| Accuracy | ±0.05° |
| Measuring Range | 0° ~360° ; 2X180°; 4X90° |
| Weight | 340g |
| Size | 137*75*33mm |
| Battery | CR2032 |
| Display Type | LCD |
| Battery | DC 3V CR2032 |
| Anti-interference Level | EMC-2 level |
| Working Temperature | 0°C~+40°C |
| Working Humidity | ≤ 85%RH |
| Protection Grade | IP54 |
| Working Hours | 1000h |
