Dial Indicator Thickness Gauge, Lens Thickness, 0-0.05" 7312S
Roll over image to zoom in Click on image to zoom
Dial Indicator Thickness Gauge, Lens Thickness, 0-0.05" 7312S

Dial Indicator Thickness Gauge, Lens Thickness, 0-0.05" 7312S

Mitutoyo SKU: 7312S
List price: €162.00 Offer price: €126.00 Excluding VAT
Why Choose Inspection Equipment
Fast Dispatch Orders dispatched quickly from our extensive warehouse stock.
46 Years of Experience Established in 1980 with decades of metrology expertise.
Technical Support Experienced specialists available before and after your purchase.
25,000+ Products One of Ireland’s largest ranges of precision measurement equipment.
Expert Advice We will help you select the right instrument for your application.
Need help choosing the right product?

Dial Indicator Thickness Gauge 0-0.05", 0,001", Lens Thickness, Ceramic Contact Elements, 7312S

This Dial Indicator Thickness Gauge enables you to measure tube wall thickness, film/paper etc. with flat contact points, resp. lens thickness or groove depth.

Specification

  • Inch-Metric: Inch
  • Functions: Adjustable anvil
  • Range: 0 - 0.05"
  • Graduation: 0.001"
  • Accuracy: ±0,001"
  • Parallelism: 5 µm
  • Max. measuring depth: 1.2"
  • Mass: 215 g
  • Contact point: Thread # 4-48UNF
