Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB
Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB
Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB
Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB
Roll over image to zoom in Click on image to zoom
Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780ABDial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780ABDial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780ABDial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB

Dial Gauge,Flat Back, ANSI/AGD Type 0,125", 0,001" 1780AB

Mitutoyo SKU: 1780AB
List price: €106.00 Offer price: €82.00 Excluding VAT
Why Choose Inspection Equipment
Fast Dispatch Orders dispatched quickly from our extensive warehouse stock.
46 Years of Experience Established in 1980 with decades of metrology expertise.
Technical Support Experienced specialists available before and after your purchase.
25,000+ Products One of Ireland’s largest ranges of precision measurement equipment.
Expert Advice We will help you select the right instrument for your application.
Need help choosing the right product?
Compact Type, Small Diameter - Inch

This is a compact, inch dial indicator with a bezel Ø 40 mm. It offers you the following benefits:
  • It is ideal for use in applications where space is limited.
  • Green limit markers are a standard accessory.
Features
Digital/Analog:
Analog
Inch-Metric:
Inch
Delivered:
With certificate of inspection, bezel clamp
Range:
0,125 "
Range
per rev.:
0,05"
Graduation:
0,001"
H MPE (Hysteresis):
0,0002"
R MPE (Repeatability):
±0,0002"
MPE first one revolution:
±0,001"
MPE first 2 1/2 revolutions:
±0,001"
Type:
ANSI/AGD Standard
Measuring force:
0,4-1,4 N
Mass:
70 g
Stem:
9.52 mm / 0.375"
Contact point:
Carbide tipped, thread: 4-48UNF
Continuous dial:
Yes
Double scale spacing:
Yes

Technical information will be added shortly.

Application information will be added shortly.

Product videos and documents will be added shortly.
