930-628 Compound Precision Sine Plate 150x150mm, with M6 Holes
930-628 Compound Precision Sine Plate 150x150mm, with M6 Holes
Roll over image to zoom in Click on image to zoom
930-628 Compound Precision Sine Plate 150x150mm, with M6 Holes930-628 Compound Precision Sine Plate 150x150mm, with M6 Holes

930-628 Compound Precision Sine Plate 150x150mm, with M6 Holes

Mitutoyo SKU: 930-628
Price: €6,566.27 Excluding VAT
  • Sine bar style of auxiliary plate.
  • It is made of tool steel, hardened and precision ground.
  • Accurate angle setting is made by gauge blocks, max. 45°.
  • 930-626 Work piece can be fixed on plate surface by tap holes and stoppers on side.
  • 930-628 and 930-629 can set the angle at two directions which go straight angularly.
  • 930-629 Permanently magnet chuck is adapted.
Features
Parallelism:
0.002 mm / 100 mm
Squareness:
0.005 mm / 100 mm
Remarks:
Compound-axis type with angle in two directions
With M6 clamping holes
Delivered:
In a carton box
Setting accuracy at 45°:
±15"
Mass:
11.3 kg

Technical information will be added shortly.

Application information will be added shortly.

Product videos and documents will be added shortly.
