811-338-10 HH-338 Durometer Type D Compact/Digital Shore D Durometer HH-300 Series 44 x 18 mm

Roll over image to zoom in Click on image to zoom

811-338-10 HH-338 Durometer Type D Compact/Digital Shore D Durometer HH-300 Series 44 x 18 mm

Name: 811-338-10 HH-338 Durometer Type D Compact/Digital Shore D Durometer HH-300 Series 44 x 18 mm
Brand: Mitutoyo
SKU: 811-338-10
Price: 1637.5 EUR
Availability: InStock

MitutoyoSKU: 811-338-10

Price:

€1,637.50

Quantity:

These compact digital durometers in the Shore D scale can test a range of different materials and offer you the following benefits:

You can use them for testing the hardness of the materials including hard rubber, hard plastics, acrylic glass, Polystyrene, rigid thermoplastics, vinyl, cellulose acetate, etc.

Specification

Model:	HH-338
Display:	Digital
Indenter b:	ø 1,25 mm
Indenter r:	R 0,1 mm
θ:	30°
Pressure foot a:	ø 3 mm
Pressure foot f:	44 x 18 mm
Indenter protrusion:	2,5 mm
Spring force WE, WA, WD:	WD=444,5H D [mN]
Dimensions (WxDxH):	151x60x28.5 mm
Mass:	0.29 kg
Connector cable for:	HH-300 Series
PIN:	Flat
U-WAVE-T:	02AZD790F
USB-ITN:	06AFM380F
DP-1VA (264-505):	959149
IT-016U 264-016-10 Hardmatic table:	937387
