U-WAVE Fit Bluetooth, IP67 Type Wireless Transmitter for Caliper 264-624
Roll over image to zoom in Click on image to zoom
U-WAVE Fit Bluetooth, IP67 Type Wireless Transmitter for Caliper 264-624

U-WAVE Fit Bluetooth, IP67 Type Wireless Transmitter for Caliper 264-624

Mitutoyo SKU: 264-624
Price: €277.11 Excluding VAT
  • Bluetooth® communication allows for wireless transmission of measurement data from digimatic micrometers and calipers to PCs, smartphones, tablets, and other terminals alike.
  • U-WAVE is now available with Bluetooth® wireless technology. With no receiver required, one PC can connect up to seven units with Mitutoyo U-WAVE Bluetooth ®. For tougher shop floor usage, dust / water-proof models are also available.
  • Bluetooth® communication not only allows for cost reduction, as it does not require the conventional dedicated receiver unit, but it also improves operability.
  • Communication distance of approx. 16 m in an open space and approx. 10 m in a factory environment.
  • The application software for transferring measurement data to smartphones, tablets, or PCs


U-WAVEPAK-BM
Available for both Android and IOS, U-WAVEPAK-BM provides users to make use of simple process control with its measurement data import function.
U-WAVEPAK NAVI
Available only for Android U-WAVEPAK NAVI guides you throughout your measurement. By using pictures, the app tells you where and how to measure as well as in what order or what device to use.
U-WAVEPAK-BW
For use on computers, U-WAVEPAK-BW communicates directly with your measuring instrument, allowing you to transfer measurement data to your computer’s software. This software can be downloaded for free on our company’s website.

Features
Wireless communication protocol:
Bluetooh 4.2 Low Energy
Modulation method:
FH-SS (Frequency Hopping Spread Spectrum Method))
Type:
U-WAVE-TCB
(U-WAVE fit Bluetooth)
Data reception
indication:
LED (green, red, orange)
Communication distance:
Approx.16 m (within visible range), 10 m (factory environment)
Power supply:
Battery CR2032 x 1 pcs.
Communication with measuring tool:
Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification
Communication frequency:
2,4 GHz band
Transmission output:
3,2 mW (5 dBm) or below (class 2)
OS compatibility:
Windows 10, Android, iOS
Battery life:
WIN 10: approx. 3 month
Dimensions (WxDxH):
56 x 30.4 x 11.5 mm
Delivered:
Including screwdriver, CR 2032 battery, key for battery case
Mass:
20 g

Technical information will be added shortly.

Application information will be added shortly.

Product videos and documents will be added shortly.
